RMS Power out­put (Si­mul­ta­ne­ous drive of both chan­nels) :

100 W x 2 (8 Ω/ohms load, 1 kHz, T.H.D. 0.05 %)

200 W x 2 (4 Ω/ohms load, 1 kHz, T.H.D. 0.1 %)

Total har­monic dis­tor­tion (1 kHz, si­mul­ta­ne­ous drive of both chan­nels, 50 W, 8 Ω/ohms load) : 0.005 %

Fre­quency re­sponse (CD, 1 W, 8 Ω/ohms load) : 5 Hz – 50 kHz ±3 dB

Damp­ing fac­tor (8 Ω/ohms load, 20 Hz – 20 kHz) : 500

Input sen­si­tiv­ity/Input im­ped­ance
PHONO (MC Low) : 250 μV / 33 Ω/ohms

PHONO (MC Mid) : 250 μV / 100 Ω/ohms

PHONO (MC High) : 250 μV / 390 Ω/ohms

PHONO (MM) : 2.3 mV / 39 kΩ/kohms

CD/TUNER/LINE/RECORDER : 220 mV / 18 kΩ/kohms

POWER AMP : 1.0 V / 18 kΩ/kohms

Out­put volt­age/Out­put im­ped­ance

PRE OUT : 1.6 V / 220 Ω/ohms

Max­i­mum al­low­able PHONO input level (1 kHz)

MC Low/Mid/High: 8 mV

MM : 80 mV

RIAA de­vi­a­tion (20 Hz – 20 kHz) : ±0.5 dB

S/N (IHF-A, 8 Ω/ohms load)

PHONO (MC Low/Mid/High) : 75 dB (0.5 mV Input)

PHONO (MM) : 88 dB (5 mV Input)

CD/TUNER/LINE/RECORDER : 107 dB (Rated out­put)

Tone Con­trol

BASS (50 Hz) : ±10 dB

TREBLE (15 kHz) : ±10 dB

Op­er­at­ing tem­per­a­ture : +5 ℃ - +35 ℃

Power con­sump­tion : 150 W

Power con­sump­tion in standby mode : 0.2 W

For the purpose of improvement, the specifications and design are subject to change without notice.
